Quick Details

  • Type: Parking Sensor System
  • Voltage: DC8V-24V
  • Power: 5W
  • Car Make: Farm Tractor, Harvester, Cotton Picker, Seeder, Tillage, Fertilizer
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: veise
  • Model Number: DF-7280513
  • Warranty: 2 Years
  • Color System:: PAL/NTSC (AUTO)
  • Display Resolution: 2400(H) X 480(V) dot
  • Wide view angle: (up/ down): 45/65 (left/right): 65/65
  • Contrast ratio: 500:1
  • Brightness:: 400cd/m2
  • Operating temperature:: -20℃ to +70℃
  • Load Dump:: DC14+87V(Td400mS) 5pulses
  • Free Operating Voltage: DC8-32V
  • Image Type: 1/3 Color CCD
  • Horizontal Resolution:: 420TV Lines

Packaging & Delivery

Delivery Time within 7-10 days after get the order

Auto parts for Heavy Equipment vision security

Veise supplying every perceivable kind of reversing camera and safety products to products to help keep their drivers,vehicles and the people around them safe

7 inches Digital Screen TFT LCD Color Monitor(Model:SP-728) Reverse Camera Systems

 Digital Screen TFT LCD Color Monitor with Removable Sun Visor. Reverse Camera Systems
OSD MENU Separately Set Each Camera Trigger Priority. Reverse Camera Systems
OSD MENU Separately Set Each Camera Reversing Image Delay Time 0-10"
OSD MENU Separately Set Each Camera Mirror/Normal image. Reverse Camera System
Manual and Automatic Switch Display Mode. Reverse Camera System
Color System:PAL/NTSC (AUTO). Reverse Camera System
Display Resolution: 2400(H) X 480(V) dot. Reverse Camera System
Support Three-channel Camera Video Inputs:1.0Vp-p75Ω. Reverse Camera System
Wide view angle(CR:10):(up/ down): 45/65 (left/right): 65/65. Reverse Camera System
Contrast ratio: 500:1. Reverse Camera System
Brightness: 400cd/m2 (Automatically Adjust Brightness to Display by According Environment)
Operating temperature: -20°C to +70°C. Reverse Camera System
Storage temperature: -30°C to +80°C. Reverse Camera System
Load Dump: DC14+87V(Td400mS) 5pulses. Reverse Camera System
Free Operating Voltage DC8-32V. Reverse Camera System
External dimensions:(L x W x T) (185X122X28)mm without mounting Sun Visor
Weight Approx: 379g. Reverse Camera System

Reverse Camera System

Aluminum Shell Waterproof IR Color Camera(MODEL:DF-8053*3)

Image Type: 1/3 Color CCD. Wireless Reverse Camera System
Horizontal Resolution:420TV Lines. Wire Reverse Camera System
Effective pixel:NTSC:510(H)X492(V);PAL:500(H)X582(V). Wire Reverse Camera System
Usable Illumination : 0Lux ( Built in 10pcs IR for Picture Support in the Dark)
Free viewing angle: 130° Wireless Reverse Camera System
Waterproof: IP69K. Wireless Reverse Camera System
Shockproof: 10G. Wireless Reverse Camera System
Video Output:1.0Vp-p75Ω. Wireless Reverse Camera System
Power supply:DC12V from Reversing Monitor. Wireless Reverse Camera System
Dimensions: 55(L) x 63(W) x 74(H)mm. Wireless Reverse Camera System

Wireless Reverse Camera System

Product Accessories. Wireless Reverse Camera System
U- Support Bracket,Angle Adjustment Screw,Removable Sun Visor,Electrical Connecting Cable,15m cable*3, Auto cigarette lighter,User's Manual
