Quick Details

  • Type: Reversing camera system
  • Voltage: DC8V-32V
  • Power: 5W
  • Car Make: Construction Equipment/Fifth Wheel/Fire Apparatus/Tractor
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Veise
  • Model Number: DF-7270111
  • Warranty: 2 Years
  • Display Resolution:: 2400(H) X 480(V) dot
  • Brightness (cd/m2): 400cd/m2
  • Monitor scheme: Techwell
  • Load Dump: DC14+87V(Td400mS) 5pulses
  • Monitor function: Built-in reverse short-circuit current protection
  • Auto dimming: Yes
  • Shockproof: 10G
  • Waterproof: IP69K
  • Anti-fogging: Yes
  • Certificate: ISO/TS16949:2009,CE,FCC,E-Mark

Packaging & Delivery

Packaging Details 4pcs/carton carton size: 43*28*28cm, carton wegiht: about 12kgs
Delivery Time within 3-7 days after get the order

   Camera Observation Video System that mounts to your Tractor, Combine, or Trailer



 Camera Observation Video System fits to many brands including: John Deere, Ford / New Holland, Case - International, Massey Ferguson, Kubota, Allis Chalmers, White / Oliver / Mpl Moline, Deutz, Yanmar, Gleaner, Steiger, Versatile, and more.   reverse







7" Digital Screen TFT LCD Monitor Free Operating Voltage DC11-32V, DC14+87V(Td400mS) 5pulses Load Dump,400cd/m2 Brightness.  truck reverse camara
Application USA Techwell Automotive Digital Video Processor,OSD Menu Separately Set Each Camera Mirror/Normal image,Trigger Priority of image,Reversing Image Delay Time 0-30"  truck accessories         600 TV Lines High Definition Camera with 18pcs IR LED's Waterproof IP69K    truck accessories camara

digital Case spare part rear view system for Case



7 inches Digital Screen TFT LCD Color Monitor (Model:SP-727)

 7"Digital Screen TFT LCD Color Monitor with Removable Sun Visor.  Rear camera for Motorhome
OSD MENU Separately Set Each Camera Trigger Priority   Rear camera for Motorhome
OSD MENU Separately Set Each Camera Reversing Image Delay Time 0-30s  Backup Camera Kit
OSD MENU Separately Set Each Camera Mirror/Normal image  truck accessories camara
Manual and Automatic Switch Display Mode.  truck accessories camara
Color System:PAL/NTSC (AUTO)   truck accessories camara
Display Resolution: 800RGB(H) X 480(V) dot   truck accessories camara
Support Two Camera Video Inputs:1.0Vp-p75Ω .  truck accessories camara
Wide view angle(CR:10):(up/ down): 45/65 (left/right): 65/65  Backup Camera Kit
Brightness (cd/m2): 400

Contrast ratio: 500:1   truck accessories camara
Back-light:Single LED   truck accessories camara
Operating temperature: -20°C to +70°C    truck accessories camara
Storage temperature: -30°C to +80°C    truck accessories camara
Load Dump: DC14+87V(Td400mS) 5pulses
Free Operating Voltage DC11-32V  truck accessories camara
External dimensions: (L x W x T) (185 x 122 x 28mm) without mounting Sun Visor
Weight Approx: 500g



Rear View Camera (DF-8058)

 Image Type: 1/3 Inch Color CCD    truck accessories camara
Horizontal Resolution:600TV Lines    truck accessories camara
Effective pixel:NTSC:510(H)X492(V);PAL:500(H)X582(V)   truck accessories camara
Usable Illumination : 0Lux ( Built in 18pcs IR for Picture Support in the Dark)
Free viewing angle: 130°

Waterproof: IP69K    truck accessories camara
Shockproof: 10G     truck accessories camara
Video Output:1.0Vp-p75Ω   truck accessories camara
Free Operating Voltage :DC11-32V    truck accessories camara
Dimensions: 75(W) x 43(H) x 38(D) mm (without mounting)

 uto shutter reversing camera car system



side view camera
